Overview

Disclaimer native proxy load balancing in Zabbix 7.0+. Zabbix 7.0 introduced proxy groups with native load balancing and high availability: proxies join a named group, hosts are assigned to the group (not individual proxies), and Zabbix automatically distributes hosts across the members and reassigns them when a proxy fails. If you're on 7.0 or later, that's the right answer for most environments configure it in Administration -> Proxy groups. This post covers the API-driven sharding approach for teams that are still on Zabbix 6.x, need custom sharding logic (e.g. pinning specific hosts to specific proxies by region or role), or want programmatic control over the reassignment rules. Both models can coexist; pick the one that matches your scale and version.

As I mentioned on my first proxy post, we deployed ZbxProxy01 against an HA Zabbix server pair. That works fine for a few hundred hosts, but once you scale into the thousands or you have hosts spread across sites, VPCs, or DMZs a single proxy is no longer the right answer.

This guide assumes you already have at least two working proxies (built using the original proxy post) and that they are visible under Administration -> Proxies in the frontend.

The two patterns we'll cover:

  1. Sharding split hosts across N proxies so each one only carries its share of the load.
  2. Failover when a proxy dies, hosts are reassigned to a healthy proxy automatically.

On Zabbix 6.x, the server has no built-in active/passive failover for proxies. "Failover" here means we move hosts off a sick proxy via the API. Done in a couple of seconds, this is more than fast enough for most production workloads. On 7.0+, proxy groups handle this natively see the disclaimer above.

Capacity Planning

Before sharding, you need to know how much each proxy can carry. Two numbers matter:

  • NVPS (new values per second) the steady-state metric throughput.
  • Required performance visible under Reports -> System information.

A reasonable rule of thumb on modest hardware (4 vCPU, 8 GB RAM, SQLite proxy):

Proxy size Hosts NVPS
Small < 200 < 500
Medium < 800 < 2000
Large < 2000 < 5000

Always size for 2x your peak. A proxy at 90% utilization has no headroom to absorb the load of a sibling that just died.

Sharding Strategy

Pick one strategy and stick with it. Mixing strategies leads to hosts that drift between proxies on every reload.

  • By location proxy-us-east, proxy-eu-west. Best when latency or firewall rules force the boundary.
  • By environment proxy-prod, proxy-stage. Best when you want to apply different polling intervals or retention.
  • By hash hash(hostname) mod N. Best when hosts are uniform and you just want even spread.
  • By role proxy-network, proxy-windows, proxy-linux. Best when templates differ wildly per role.

For the rest of this post we'll use the hash strategy because it's the easiest to automate.

Sharding with the Zabbix API

The Zabbix API exposes a proxy.update and host.update endpoint. We'll use Powershell to:

  1. Pull every host.
  2. Hash the hostname.
  3. Pick a proxy by hash mod N.
  4. Re-assign the host if it doesn't already match.

1. A Tiny Powershell Wrapper

Save this as ZabbixApi.psm1 so other scripts can reuse it.

function Connect-Zabbix
{
    [CmdletBinding()]
    param(
        [Parameter(Mandatory)]
        [string]$Url,        # https://zabbix.example.com/api_jsonrpc.php

        [Parameter(Mandatory)]
        [pscredential]$Credential
    )
    begin
    {

        $headers = @{"Content-Type" = 'application/json-rpc' }
        $body = @{
            jsonrpc = '2.0'
            method  = 'user.login'
            params  = @{
                username = $Credential.UserName
                password = $Credential.GetNetworkCredential().Password
            }
            id      = 1
        } | ConvertTo-Json -Depth 99
    }
    process
    {

        $resp = Invoke-RestMethod -Uri $Url -Method Post -Body $body -Headers $headers -ErrorAction Stop
        return [pscustomobject]@{
            PSTypeName = "ZabbixSession"
            Url        = $Url
            Token      = $resp.result
        }
    }
}

function Invoke-Zabbix
{
    [CmdletBinding()]
    param(
        [Parameter(Mandatory)]
        [psobject]$Session,

        [Parameter(Mandatory)]
        [string]$Method,

        [Parameter()]
        [hashtable]$Params = @{}
    )
    begin
    {
        if ('ZabbixSession' -inotin @($Session.PSTypeNames))
        {
            throw "Invalid session"
        }
        $headers = @{"Authorization" = "Bearer $($Session.Token)" }
        $body = @{
            jsonrpc = '2.0'
            method  = $Method
            params  = $Params
            id      = (Get-Random)
        } | ConvertTo-Json -Depth 99
    }
    process
    {
        $resp = Invoke-RestMethod -Uri $Session.Url -Method Post -Body $body -ContentType 'application/json' -Headers $headers
        if ($resp.error)
        {
            throw "$($resp.error.message): $($resp.error.data)"
        }
    }
    end
    {

        return $resp.result
    }
}

Export-ModuleMember -Function Connect-Zabbix, Invoke-Zabbix

2. Rebalance Script

[CmdletBinding()]
param()
begin
{
    Import-Module ./test.psm1

    function Get-StableHash
    {
        param
        (
            [Parameter()]
            [string]$Text
        )
        process
        {
            $sha = [System.Security.Cryptography.SHA1]::Create()
            $bytes = $sha.ComputeHash([Text.Encoding]::UTF8.GetBytes($Text))
            return [BitConverter]::ToUInt32($bytes, 0)
        }
    }
}
process
{
    $connection = @{
        Url = 'https://zabbix.example.com/api_jsonrpc.php'
        Credential = (Get-Credential)
    }
    $session = Connect-Zabbix @connection
    # Only proxies that should receive load
    $proxies = Invoke-Zabbix -Session $session -Method 'proxy.get' -Params @{
        output = @('proxyid', 'name', 'state', 'operating_mode')
        filter = @{ 'operating_mode' = '0' }              # 0 = active proxy
    } | Sort-Object host

    if ($proxies.Count -eq 0) { throw "No active proxies found" }

    $hosts = Invoke-Zabbix -Session $session -Method 'host.get' -Params @{
        output           = @('hostid', 'host', 'proxyid')
        selectInterfaces = @('ip')
    } | Where-object { $_.proxyid -gt 0 }


    $moves = @()
    foreach ($h in $hosts)
    {
        $idx = (Get-StableHash $h.host) % $proxies.Count
        $target = $proxies[$idx]
        if ($h.proxyid -ne $target.proxyid)
        {
            $moves += [pscustomobject]@{
                Host    = $h.host
                From    = ($proxies | Where-Object proxyid -eq $h.proxyid).host
                To      = $target.host
                HostId  = $h.hostid
                ProxyId = $target.proxyid
            }
        }
    }

    Write-Host "$($moves.Count) hosts will be reassigned."

    foreach ($m in $moves)
    {
        $null = Invoke-Zabbix -Session $session -Method 'host.update' -Params @{
            hostid      = $m.HostId
            proxyid     = $m.ProxyId
        }
        Write-Verbose "$($m.Host): $($m.From) -> $($m.To)"
    }
}

Run this with -WhatIf-style dry-run by commenting out the final host.update call until you trust the math.

3. Schedule It

A nightly scheduled task (Windows) or cron job (Linux) keeps the cluster balanced as new hosts come in via autoregistration:

# Windows Task Scheduler
$actionParams = @{
    Execute  = 'powershell.exe'
    Argument = '-NoProfile -File C:\Scripts\Rebalance-ZabbixProxies.ps1'
}
$action  = New-ScheduledTaskAction @actionParams
$trigger = New-ScheduledTaskTrigger -Daily -At 2am

$taskParams = @{
    TaskName  = 'Zabbix Proxy Rebalance'
    Action    = $action
    Trigger   = $trigger
    RunLevel  = 'Highest'
    User      = 'SYSTEM'
}
Register-ScheduledTask @taskParams

Failover

The same script doubles as failover logic. Add a health check at the top if a proxy hasn't checked in within 5 * ConfigFrequency, drop it from the rotation:

$now = [int][double]::Parse((Get-Date -UFormat %s))

$healthy = $proxies | Where-Object {
    $details = Invoke-Zabbix -Session $session -Method 'proxy.get' -Params @{
        output    = @('proxyid','host','lastaccess')
        proxyids  = @($_.proxyid)
    }
    ($now - [int]$details.lastaccess) -lt 600    # 10 minutes
}

if ($healthy.Count -lt $proxies.Count)
{
    Write-Warning "Excluding dead proxies: $((Compare-Object $proxies $healthy -Property host).InputObject.host -join ', ')"
}

$proxies = $healthy

When a proxy dies, the next run of the script (or a manual run) will hash every host against the surviving proxies and reassign in seconds.

Combine this with a Zabbix trigger on the zabbix[proxy,<name>,lastaccess] internal item to automatically run the script via an action when a proxy is declared down.

Verify From the Frontend

After a rebalance:

  • Administration -> Proxies should show all healthy proxies with a roughly equal Item count.
  • Reports -> System information -> Required server performance, NVPS should drop on the previously overloaded proxy.
  • Each host's Monitored by proxy field reflects the new owner.

What to Do Next

A handful of API calls and a hash function turn N independent proxies into a self-balancing fleet. The pattern is small consistent-hash hostnames to proxies, rebalance only on proxy count change, never touch the UI but the operational discipline is "what runs on a schedule, what runs on event, and what's the safety check before we move 5,000 hosts in one go".

Three concrete moves to make balancing safer the next time you grow the fleet:

  1. Run the hash assignment as a dry-run first. Print the proposed move list (host -> old-proxy -> new-proxy) before issuing any host.update calls. A bug in the hash code would otherwise migrate the entire fleet at once.
  2. Throttle moves per minute. Bulk-reassigning thousands of hosts simultaneously hammers the server and the proxies. A small Start-Sleep between API calls keeps queue depth bounded and gives you a chance to abort if anything goes wrong.
  3. Add a per-proxy NVPS guard. Even with consistent hashing, a single noisy host can push one proxy into the red. A scheduled check that compares actual NVPS to an expected ceiling (and auto-pages) is the safety net the hash function alone can't provide.

Pairs naturally with the Low-Level Discovery post (because LLD multiplies item counts and makes proxy capacity planning sharper) and the architecture post (which gives you the formula for how many proxies you actually need).
